AVI LTE 8445 MIMO WAP ROUTER

The AVI LTE 8445 is optimised for operation in harsh environments that require Ethernet, 4G-LTE, Wi-Fi and Routing technology, using high-grade components, a tough industrial case and extended operating temperature range.

The AVI LTE 8445 is a new generation LTE, UMTS and Wi-Fi Router Modem providing local Wi-Fi access and multiple Ethernet connectivity with enhanced 4G-LTE MIMO WAN uplink.

The AVI LTE 8445 is capable of 4G-LTE download speeds of up to 100Mbps and upload speeds of up to 50Mbps.

In the event of loss of 4G-LTE, the AVI LTE 8445 can support data on the UMTS and other available networks to maintain WAN connectivity. Built-in GPS provides embedded vehicle or asset tracking via web-based solutions or Google Earth.

Coupled with the on-board accelerometer, temperature sensor and data logging, this device assists in the tracking of machinery condition and occupational health and safety monitoring.

The rugged AVI industrial chassis, complemented by high performance components, provides reliable and scaleable data, voice and video communications to stationary and mobile network nodes across wireless links.

For mission-critical mobile communications, the AVI LTE 8445 can be deployed to take advantage of public or private 4G-LTE networks, with fallback to 3G and other radio technologies for redundancy. The 1x Gigabit (routed) Ethernet and 4x 10/100 Ethernet (switched) interfaces are configurable for switching or routing, and provide maximum network configuration flexibility in a small and rugged package.

Industrial connectors for power, data and RF ensure reliable physical connections that resist vibration and provide ingress protection, wide range DC power input for connection to 12 to 48V vehicle or battery systems. AC mains power may be provided via AVI AC-DC power supplies.

Using high-grade components, a tough industrial case and extended operating temperature range, the AVI LTE 8445 is optimised for operation in harsh environments that require Ethernet, 4G-LTE, Wi-Fi and Routing technology.

Key Features

  • Industrial LTE and UMTS Data Modem with Wi-Fi and GNSS
  • 5x RJ45 Ethernet
  • Support for LTE, DC-HSPA+, HSPA+, HSDPA, HSUPA, WCDMA, GSM, GPRS and EDGE
  • Graceful Disconnect from LTE Network
  • 802.11a/b/g/n Wi-Fi
  • 3-axis Accelerometer with Data Logging
  • GPS (GNSS)
  • 12-24 VCD Input (Nominal)
  • Internal LiPO Battery Supporting UPS
Router Router
LTE LTE
Wifi Wi-Fi Hotspot
Ethernet Multiple Ethernet Connection
GPS Built-in GPS
